Franklin Electric C1 20XC1-05p4-2W115 Septic Pump with Float
Franklin Electric C1 Submersible Septic Effluent Pump, Stainless Steel, 20 GPM with Float
Please Note: The float switch and pump are not already wired together. The customer will need to connect the two items.
Designed for use as a gray water/septic effluent pump in drip and sprinkler service applications, the C1 Series cistern pump provides high performance and long life in less than clean water conditions. The C1 Series pump is able to pass solids up to 1/8-inch without having a negative effect on the internal hydraulic components. Franklin electric C1 series high head submersible effluent pump 20xC1-05p4-2W115 - bottom suction.
The water level around the pump should stay above the valve at the top of the pump. That means that the lowest point of the float switch controlling the pump should be above the valve. The life of the pump can be shortened if there is not enough water above the inlet of the pump.
