ATER Mechanical Float Switch N/O w/10' Cord WA13-10'

ATER
Original price $28.00 - Original price $28.00
Original price
$28.00
$28.00 - $28.00
Current price $28.00

Key Features Specs Warranty Introducing the ATER WA13-10' Pump Float Switch, the ultimate solution for your wastewater pumping needs! This m...

View full details
Original price $28.00 - Original price $28.00
Original price
$28.00
$28.00 - $28.00
Current price $28.00

ATER Narrow Angle Mechanical Float Switch w/10' Cord NA13-10'

ATER
Original price $28.00 - Original price $28.00
Original price
$28.00
$28.00 - $28.00
Current price $28.00

Key Features Specs Warranty The ATER Control Float Switch is reliable, and designed to manage water levels in various septic applications. It ...

View full details
Original price $28.00 - Original price $28.00
Original price
$28.00
$28.00 - $28.00
Current price $28.00

SJE-RHOMBUS P/N 1002713 Mechanical Aerobic Septic Float Switch With 10' Lead

SJE Rhombus
Original price $65.00 - Original price $65.00
Original price
$65.00
$65.00 - $65.00
Current price $65.00

Key Features Specs Warranty SJE-Rhombus Pumpmaster is the ideal float switch for 1/2 HP, 120V pump when directly connected and power is flow...

View full details
Original price $65.00 - Original price $65.00
Original price
$65.00
$65.00 - $65.00
Current price $65.00

ATER Narrow Angle Mechanical Float Switch w/15' Cord NA13-15'

ATER
Original price $32.00 - Original price $32.00
Original price
$32.00
$32.00 - $32.00
Current price $32.00

Key Features Specs Warranty ATER Pumps Float Switch Pump Duty Normally Open Narrow Angle Mechanical Float w/15' Cord 115/230 VAC 50/60 Hz. I...

View full details
Original price $32.00 - Original price $32.00
Original price
$32.00
$32.00 - $32.00
Current price $32.00

SJE SignalMaster®10ft Mechanically-Activated, Narrow-Angle Control Switch

Wholesale Septic Supply
Original price $40.00 - Original price $40.00
Original price
$40.00
$40.00 - $40.00
Current price $40.00

Key Features Specs Warranty The 1011678 is a narrow angle float switch. That means that the float switch does not have to raise up very high...

View full details
Original price $40.00 - Original price $40.00
Original price
$40.00
$40.00 - $40.00
Current price $40.00

Amp Pro Mechanical Float Switch with Piggyback

SJE Rhombus
Original price $40.00 - Original price $55.00
Original price
$40.00 - $55.00
$40.00 - $55.00
Current price $40.00

Key Features Specs Warranty The Amp Pro Mechanical Float Switch is a specially made float that has 14 gauge heavy duty electrical wire with a...

View full details
Original price $40.00 - Original price $55.00
Original price
$40.00 - $55.00
$40.00 - $55.00
Current price $40.00

MDI Normally Closed Float Switch

Wholesale Septic Supply
Original price $37.00 - Original price $45.00
Original price
$37.00 - $45.00
$37.00 - $45.00
Current price $37.00

Key Features Specs Warranty These high quality float switches are designed for pump duty loads. The float switch is as normally closed or pu...

View full details
Original price $37.00 - Original price $45.00
Original price
$37.00 - $45.00
$37.00 - $45.00
Current price $37.00

ATER Mechanical Float Switch w/20' Cord WA13-20'

ATER
Original price $40.00 - Original price $40.00
Original price
$40.00
$40.00 - $40.00
Current price $40.00

Key Features Specs Warranty Introducing the ATER WA13-20' Pump Float Switch, the ultimate solution for your wastewater pumping needs! This m...

View full details
Original price $40.00 - Original price $40.00
Original price
$40.00
$40.00 - $40.00
Current price $40.00

ABS Nylon Cable Clamp

SJE Rhombus
Original price $16.00 - Original price $16.00
Original price
$16.00
$16.00 - $16.00
Current price $16.00

Key Features Specs Warranty Description: Clamp Design: The clamp is designed as a U-shaped or C-shaped bracket with an opening that runs al...

View full details
Original price $16.00 - Original price $16.00
Original price
$16.00
$16.00 - $16.00
Current price $16.00

Yellow Normally Open Mechanical Float Switch

Wholesale Septic Supply
Original price $50.00 - Original price $50.00
Original price
$50.00
$50.00 - $50.00
Current price $50.00

Key Features Specs Warranty Instead, a metal ball rolls back and forth inside of the float. When the ball rolls to one side, the contacts wi...

View full details
Original price $50.00 - Original price $50.00
Original price
$50.00
$50.00 - $50.00
Current price $50.00

ATER Narrow Angle Mechanical Float Switch w/20' Cord NA13-20'

ATER
Original price $36.50 - Original price $36.50
Original price
$36.50
$36.50 - $36.50
Current price $36.50

Key Features Specs Warranty ATER Pumps Float Switch Pump Duty Normally Open Narrow Angle Mechanical Float w/20' Cord 115/230 VAC 50/60 Hz. I...

View full details
Original price $36.50 - Original price $36.50
Original price
$36.50
$36.50 - $36.50
Current price $36.50

ATER Mechanical Float Switch w/15' Cord WA13-15'

ATER
Original price $34.00 - Original price $34.00
Original price
$34.00
$34.00 - $34.00
Current price $34.00

Key Features Specs Warranty Introducing the ATER WA13-15' Pump Float Switch, the ultimate solution for your wastewater pumping needs! This m...

View full details
Original price $34.00 - Original price $34.00
Original price
$34.00
$34.00 - $34.00
Current price $34.00

SJE-RHOMBUS P/N 1054209 Aerobic Septic Float Switch With 20' Lead

SJE Rhombus
Original price $63.00 - Original price $63.00
Original price
$63.00
$63.00 - $63.00
Current price $63.00

Key Features Specs Warranty SJE-Rhombus Pumpmaster is the ideal float switch for 1/2 HP, 120V pump when directly connected and power is flowin...

View full details
Original price $63.00 - Original price $63.00
Original price
$63.00
$63.00 - $63.00
Current price $63.00
Sold out

SJE-RHOMBUS P/N 519663 Aerobic Septic Float Switch With 15' Lead

SJE Rhombus
Original price $50.00 - Original price $50.00
Original price
$50.00
$50.00 - $50.00
Current price $50.00

Key Features Specs Warranty The Pumpmaster float switch can also be used on 2 HP pumps that are running 220V as the amp draw is less on 220V m...

View full details
Original price $50.00 - Original price $50.00
Original price
$50.00
$50.00 - $50.00
Current price $50.00
Sold out

Cast Iron Cable Weight for Float

Wholesale Septic Supply
Original price $17.00 - Original price $17.00
Original price
$17.00
$17.00 - $17.00
Current price $17.00

Key Features Specs Warranty A one pound float switch weight. 2" wide by 2.63" tall. A grey iron weight with zinc plating. The weight comes wi...

View full details
Original price $17.00 - Original price $17.00
Original price
$17.00
$17.00 - $17.00
Current price $17.00

SJE Rhombus SNO Sensor Float 30' Lead

SJE Rhombus
Original price $52.00 - Original price $52.00
Original price
$52.00
$52.00 - $52.00
Current price $52.00

Key Features Specs Warranty This particular float has a long lead of 30 feet, so it is ideal for deep lift stations and septic systems with ...

View full details
Original price $52.00 - Original price $52.00
Original price
$52.00
$52.00 - $52.00
Current price $52.00
Sold out

ATER Mechanical Float Switch w/30' Cord WA13-30' With Weight

ATER
Original price $50.00 - Original price $68.00
Original price
$50.00 - $68.00
$50.00 - $68.00
Current price $50.00

Key Features Specs Warranty Pump Duty Normally Open Mechanical Float w/30' Cord 115/230 VAC 50/60 Hz. IP 68 Protection Rating, come with weig...

View full details
Original price $50.00 - Original price $68.00
Original price
$50.00 - $68.00
$50.00 - $68.00
Current price $50.00

MDI JCM20W2000 Float Switch

Wholesale Septic Supply
Original price $45.00 - Original price $45.00
Original price
$45.00
$45.00 - $45.00
Current price $45.00

Narrow angle mercury float, pump down, 20 ft cord. 13 AMPS @ 120 VAC5 AMPS @ 240 VAC

Original price $45.00 - Original price $45.00
Original price
$45.00
$45.00 - $45.00
Current price $45.00

ATER Mechanical Float Switch w/50' Cord WA13-50' With Weight

ATER
Original price $75.00 - Original price $93.00
Original price
$75.00 - $93.00
$75.00 - $93.00
Current price $75.00

Key Features Specs Warranty Pump Duty Normally Open Mechanical Float w/50' Cord 115/230 VAC 50/60 Hz. IP 68 Protection Rating, come with wei...

View full details
Original price $75.00 - Original price $93.00
Original price
$75.00 - $93.00
$75.00 - $93.00
Current price $75.00

MDI JCM20W3000W Float Switch

Wholesale Septic Supply
Original price $65.00 - Original price $65.00
Original price
$65.00
$65.00 - $65.00
Current price $65.00

Narrow angle mercury float, pump down, 30 ft cord and weight 13 AMPS @ 120 VAC5 AMPS @ 240 VAC

Original price $65.00 - Original price $65.00
Original price
$65.00
$65.00 - $65.00
Current price $65.00
Sold out

ATER Narrow Angle Mechanical Float Switch w/50' Cord NA13-50'

ATER
Original price $62.50 - Original price $62.50
Original price
$62.50
$62.50 - $62.50
Current price $62.50

Key Features Specs Warranty ATER Pumps Float Switch Pump Duty Normally Open Mechanical Float Narrow Angle w/50' Cord 115/230 VAC 50/60 Hz. I...

View full details
Original price $62.50 - Original price $62.50
Original price
$62.50
$62.50 - $62.50
Current price $62.50

ATER Narrow Angle Mechanical Float Switch w/30' Cord NA13-30'

ATER
Original price $46.00 - Original price $46.00
Original price
$46.00
$46.00 - $46.00
Current price $46.00

Key Features Specs Warranty ATER Pumps Float Switch Pump Duty Normally Open Mechanical Float Narrow Angle w/30' Cord 115/230 VAC 50/60 Hz. I...

View full details
Original price $46.00 - Original price $46.00
Original price
$46.00
$46.00 - $46.00
Current price $46.00

MDI JCM20W2000W Float Switch with Weight

Wholesale Septic Supply
Original price $58.00 - Original price $58.00
Original price
$58.00
$58.00 - $58.00
Current price $58.00

Narrow angle mercury float, pump down, 20 ft cord. with weight 13 AMPS @ 120 VAC5 AMPS @ 240 VAC

Original price $58.00 - Original price $58.00
Original price
$58.00
$58.00 - $58.00
Current price $58.00
Sold out

Septic Tank Float Switches

Overview

Float switches are an integral part of your septic system they tell your septic pump to turn on and off, they also let you know when there is a problem and the water level is too high. There are a couple of different float switches, and they serve various functions.We will go over that briefly below.

Control duty floats control alarms, and pumps in some cases and are not directly tied to the pump. They are wired directly to the control panel, and then the control panel has a relay that activates anything that needs to be done. The control duty floats or sensor floats have a maximum amp rage rating of five amps and are mercury activated. The basics of the operation are the float come up closing contacts and that in turn hit the relay switch which enables and takes the load of whatever was turned on.

Pump duty or pump floats are wired directly to the pump wires and are designed to take on the amp load of a pump motor running. The electrical charge that powers the pump runs through the float switch. Pump floats have an amp rating of 13-15 amps and have a lock amp rotor rating of 50-96 amps. Pump duty floats should always be changed when a new pump is installed if not you run the risk of ruining your new pump. The old pump on the system would have pulled more amps due to age as they get older they start drawing more amps and eventually that's why they fail. Because of this, they damage the float, so that is why it is necessary to change the float switch at the same time.

Float switches are an addition to an electrical circuit that allows for autonomous detection of fluid levels. Their primary use is to close a circuit when the fluid level reaches a particular height or depth. A closed circuit means that electricity is able to flow through the circuit’s components and power them. On the other hand, an open circuit is one that will not allow current to pass through the components. As fluid levels rise, a float switch will be lifted up with the water level. This means that the float switch will go from facing downwards to facing upwards. The upward orientation will typically cause a float switch to close, but the direction in which a float switch closes depends on the specific float switch.

There are a few terms that will tell you if a float switch will close a circuit if it is in the up or down position. The normal position of a float switch is hanging down. A float switch will hang down from where it is mounted when the fluid level is low. Septic systems typically want to close a circuit and turn on a pump when the fluid level gets to a certain height. This means that float switches in septic systems will spend a lot of time in the down position waiting to detect a high-water level.

A normally open float switch will open a circuit when it is in the normal position. This means the circuit is effectively turned off when the fluid level is low. A normally open system will have a closed circuit when the water level is high. This orientation makes the normally open float switch a good fit for most septic systems. A typical septic system will want to pump out effluent when too much of it builds up in the tank. The rising effluent level will lift up the float switch and cause the circuit to close. The closed circuit will turn on the effluent pump and return the effluent to the desired height.

A normally closed float switch will operate in reverse of a normally open float switch. Normally closed means current will flow with a low fluid level, and current will not flow when the fluid level is high. This system may be used when the user needs the fluid level in a system to be above a minimum height

There are two general types of mechanisms that a float switch may use to close the electrical circuit. The first type of mechanism is mercury. The mercury within the float switch will move as the fluid level changes, and that movement with open or close the system.

The second type of mechanism is more mechanical in nature. A mechanical float switch will contain a ball bearing. As the fluid level changes, the ball will roll within the float switch. The ball will then push on the internal components of the float switch and cause the circuit to open or close.

Float switches can also come in the wide angle or narrow angle varieties. A wide-angle float switch has to move a relatively far distance to engage the system. These types of float switches can be used if a fair amount of change in fluid level is acceptable or to be expected. Narrow angle float switches will move a relatively shorter distance before they engage the system. These types of float switches should be considered if the user wants to maintain a more constant fluid level.

In the case of septic systems, the float switch is used to detect the level of effluent in a septic tank. The effluent pump will begin to pump when the float switch is closed. This will cause the effluent level to drop and will eventually open the circuit when the level gets low enough. This system will allow your septic system to regulate the level of effluent in the tank without requiring the user to look inside of the tank to determine if the pump should be engaged.

It is a good idea to change out the float switch in your septic system when you change your effluent pump. If an effluent pump stops working, the level of effluent in your tank will rise above acceptable levels. Your float switch will notice the high-water level and will try to turn on the pump. However, a broken pump will not empty your tank. This can lead to a situation where your float switch is kept on for an extended period of time. A constant current may cause the float switch to become stuck in the on position. This situation could cause your new effluent pump to be run continuously. This is because the float switch has been damaged and is still telling the pump to empty an already empty tank. This situation can cause your pump to burn up or simply shorten the overall life of your new pump. Replacing the float switch when you get a new effluent pump will keep your system running smoothly for a longer amount of time.

Keep in mind that many systems require more than one float switch. Systems that use a timer may have an override float switch. This override switch is to activate the pump when the fluid level becomes too high. Some systems may use an array of float switches to regulate the fluid level, override, and an alarm. It is important to know the number and types of float switches that your septic system requires.

  • Float switches are used to turn things on and off based on fluid level
  • Know if you need a normally open or normally closed float switch
  • Know if you need a wide-angle float switch or narrow-angle float switch
  • Change out the float switch when you change your effluent pump
